Connector End Plate Test

MTT provides end plate testing with 0.2% FS load accuracy, covering full speed range of 0.1-250mm/min insertion and removal, micrometer level deformation monitoring, and 3-5 working days of rapid output reports to help enterprises meet American/German/national standard certifications and ensure zero failure of connectors after millions of vibrations.



Connector End Plate Test

| Project Overview



The connector end plate testing program, especially the test for pin retention force, is a critical step in evaluating the mechanical strength performance of pins in plugs, sockets, and connectors. This program provides manufacturers with key data on product durability and reliability by precisely measuring pin retention under different conditions, ensuring that products maintain stable connection performance in daily use and preventing performance degradation or disconnection issues.





| Test Objective



The core objective of this program is to help manufacturers by precisely measuring pin retention force:



1. To assess product durability and reliability, ensuring stable connection performance during daily use.



2. Identify and improve potential issues in product design and manufacturing processes, thereby enhancing product quality and customer satisfaction.



3. Provide the necessary testing data for product certification and market entry, strengthening product competitiveness in the marketplace.





| Project Advantages



High Accuracy: Load accuracy reaches 0.2% FS, ensuring the precision of test results.



Multiple Machines: Equipped with five insertion–withdrawal force testing machines to meet large-scale testing demands.



Wide Test Speed Range: Covers from 0.1 mm/min to 250 mm/min, accommodating diverse testing requirements.



Short Testing Cycle: Typical testing cycles last 3–5 working days, with expedited services available to shorten product development timelines.





| Applied Products and Test Standards





Applied Products: Electric plugs, electric sockets, connectors.

Test Standards: QC/T 1067.1-2017, USCAR 2-8, GMW 3191-2019.
