Mechanical environment reliability

Test Background

Quick connectors need to withstand environmental stresses such as vibration, temperature changes, and humidity during transportation, installation, and operation. Insufficient mechanical environmental reliability may lead to connector loosening, seal failure, or material aging.

Test Introduction

Through vibration tests, temperature cycle tests, damp-heat aging tests, and extreme temperature storage tests, the environmental stresses that quick connectors are subjected to during their entire life cycle are simulated to verify their environmental adaptability.

Testing Objectives

Verify that there is no leakage or loosening under vibration conditions

Evaluate the impact of temperature cycles on sealing materials

Ensure that there is no corrosion or aging in a damp-heat environment

Verify the functional integrity after extreme temperature storage

Test Standards

IEC 60068-2-6 Vibration test

IEC 60068-2-14 Temperature change test

IEC 60068-2-30 Damp-heat test

GB/T 2423 Environmental test series standards

Applicable Products/Fields

Suitable for various types of liquid-cooled quick connectors, outdoor cabinet connectors, vehicle-mounted liquid-cooled connectors, etc.

Test Content

Vibration test: Random vibration from 5 to 2000 Hz, 20g

Temperature cycling test: Temperature cycling from -40°C to 85°C, 100 cycles

Wet-heat aging test: 85°C/85%RH, 1000 hours

Extreme temperature storage: Store at -40°C for 24 hours and at 75°C for 72 hours

Project Advantages

Capable of applying combined vibration and temperature stresses simultaneously

Compares changes in insertion and extraction forces and leakage rates before and after the test

Provides environmental adaptability rating and service life assessment

Laboratory Configuration

Electromagnetic vibration test system

High and low temperature alternating humidity test chamber

Insertion and extraction force tester (comparison before and after the test)

Helium mass spectrometer leak detector (comparison before and after the test)

FAQ
Q: Will the insertion and extraction forces change after wet-heat aging? A: The sealing material may swell or harden, resulting in changes in the insertion and extraction force, which need to be controlled within ±20%.
