Safety test

Test Background

The liquid-cooling system operates under pressure (0.3-1.0 MPa). Once the coolant leaks, it may cause safety accidents such as electrical short-circuits, equipment damage, and even fires. The safety test is the red line for ensuring personnel safety and stable operation of equipment.

Test Introduction

The safety test covers explosion-proof and flame-retardant tests, leakage detection, electrical safety regulations, and emergency heat-dissipation tests. It comprehensively evaluates the system's safety protection ability under abnormal operating conditions to ensure that no safety accidents occur under any failure mode.

Testing Objectives

Verify the safety of the system under abnormal operating conditions such as over-pressure and leakage

Evaluate the flame-retardant performance and electrical insulation ability of materials

Ensure the reliability of leakage detection and emergency heat-dissipation functions

Meet the requirements of international safety certifications such as UL/EN

Test Standards

EN/UL 62368-1 Safety requirements for audio/video, information and communication technology equipment

GB/T 42880-2023 Technical specification for data center safety

YD/T 4024-2022 General technical requirements and test methods for liquid-cooled server systems in data centers

Applicable Products/Related Fields

Suitable for various liquid-cooled data centers, AI computing power centers, edge computing nodes, immersion liquid-cooled systems, etc.

Test Content

Explosion-proof and flame-retardant test: Verification of UL94 V-0 grade for materials

Leakage detection test: Helium mass spectrometry leak detection, leakage rate ≤ 1×10⁻⁶ Pa·m³/s

Electrical safety test: Insulation resistance, withstand voltage, grounding resistance

Emergency heat dissipation test: Passive heat dissipation ability under power failure/pump failure

Project Advantages

High-sensitivity helium inspection equipment capable of detecting micron-level leaks

Electrical safety testing covering IEC/UL/GB standards

Emergency heat dissipation testing simulating the harshest fault scenarios

Laboratory Configuration

Helium mass spectrometer leak detector (sensitivity: 5×10⁻¹² Pa·m³/s)

Safety comprehensive analyzer (withstand voltage of 5 kV, insulation of 1 TΩ)

Flame retardancy tester (UL94 horizontal/vertical combustion)

Emergency heat dissipation test platform

FAQ
Q: What is the concept of a leakage rate of 1×10⁻⁶ Pa·m³/s? A: It is equivalent to a gas volume of about 0.001 ml leaking per second under 1 atmosphere, which is one-ten-thousandth of a drop of water and belongs to an ultra-high sealing level.
