Interface adaptability and chemical tests

Test Background

The connection device needs to be docked with various components such as quick connectors, cold plates, and CDUs. The interface size, tolerance, and material compatibility directly affect the system assembly efficiency and long-term reliability.

Test Introduction

Test the insertion and extraction life of quick-connect joints, conduct cleanliness analysis and coolant compatibility tests to ensure the safety and compatibility of system connections and promote the decoupled application of multi-vendor components.

Testing Objectives

Verify that the dimensional tolerances of the interfaces meet the interchangeability requirements

Evaluate the compatibility of connectors from different brands

Detect the internal cleanliness of the connecting device to prevent contamination

Ensure long-term compatibility between the material and the coolant

Test Standards

T/CESA 1249.2-2023 Technical specification for connection systems

OCP UQD interchangeability test standard

ISO 16232 Cleanliness determination

ASTM D2570 Coolant compatibility test

Applicable Products/Fields

Suitable for components that need to be mutually matched, such as quick-connect fittings, water separator interfaces, and corrugated pipe joints in liquid cooling systems.

Test Content

Interface dimension inspection: Use calipers and plug gauges to detect tolerances

Interchangeability test: Cross insertion and extraction verification of connectors from different brands

Cleanliness analysis: Particle counting and composition analysis of the flushing fluid

Coolant compatibility test: Immersion corrosion and swelling tests of materials

Project Advantages

Covers multi-dimensional compatibility in mechanics, dimensions and chemistry

Supports interchangeability verification in accordance with OCP standards

Provides cleanliness level reports and pollution source analysis

Laboratory Configuration

Precision measuring tools (calipers, plug gauges, coordinate measuring machines)

Insertion and extraction force tester

Cleanliness analysis system

Constant-temperature soaking test chamber

FAQ
Q: Can UQDs from different brands be inter-plugged?
A: UQD products from mainstream manufacturers have passed the OCP interchangeability verification and can be inter-plugged. However, it is recommended to conduct cross-testing verification before the first use.
