Reliability and durability test

Test Background

The CDU needs to operate continuously for a long time. Core components such as pumps, valves, and heat exchangers may experience performance degradation or failure during continuous operation. Reliability verification is the key to ensuring the stable operation of the system throughout its life cycle.

Test Introduction

Through projects such as aging tests, redundant switching tests, and power-off protection tests, simulate the performance of the CDU under long-term operation and fault modes to verify its reliability and fault tolerance.

Testing Objectives

Verify the stability of continuous operation for more than 72 hours

Ensure automatic redundant switching in case of pump/heat exchanger failure

Test the system's ability to maintain and recover its state after a power outage

Evaluate the reliability index (MTBF) throughout the life cycle

Test Standards

T/CESA 1249.3-2023 Technical specification for cooling capacity distribution units

GB/T 37079 Equipment reliability test

OCP CDU Reliability Verification Guide

Applicable Products/Related Fields

Suitable for liquid cooling systems for critical infrastructure, AI computing power centers, and data centers that require high availability guarantees.

Test Content

Aging test: Continuous operation under rated conditions for 72-1000 hours

Redundancy switching test: Automatic switching of the standby pump when the main pump fails

Power failure protection test: Parameter retention and automatic restart after an unexpected power failure

Self-diagnostic fault test: Simulate various types of faults to detect alarm functions

Project Advantages

Capable of simulating simultaneous triggering of multiple fault modes

Real-time monitoring of pressure/flow fluctuations during switching

Provides MTBF estimation and maintenance recommendations

Laboratory Configuration

Long-term operation monitoring platform

Fault simulation injection device

Redundant switching test system

Data recording and analysis software

FAQ
Q: Will the server operation be affected during CDU redundant switching?
A: High-quality CDUs can achieve seamless switching. During the switching process, the pressure/flow fluctuation is controlled within ±5%, which has no impact on the server.
