Safety test

Test Background

Valves are responsible for flow control and fault isolation in the liquid-cooling system. Their sealing performance, pressure resistance, and electrical safety directly affect the operating safety of the system. Valve failure may lead to the inability to isolate leaks or cause misoperations.

Test Introduction

The safety experiment comprehensively verifies the safety performance of the valve under rated working conditions and abnormal conditions through the pressure test, leakage rate test, insulation resistance test, action response test and EMC test.

Testing Objectives

Verify the structural strength of the valve body under 1.5 times the working pressure

Detect the leakage rate in the closed state

Ensure electrical insulation and electromagnetic compatibility

Verify the action reliability in the fault mode

Test Standards

T/CESA 1249.2-2023 Technical specification for connection systems

GB/T 13927 Industrial valves-Pressure testing

EN/UL 62368-1 Electrical safety requirements

IEC 61000 EMC test standard

Applicable Products/Fields

Suitable for solenoid shut-off valves, electric control valves, automatic fault switching valves, manual valves, etc.

Test Content

Pressure test: Maintain the pressure at 1.5 times the working pressure for 15 minutes

Leakage rate test: Measure the leakage by the pressure drop method in the closed state

Insulation resistance test: The insulation between the coil and the housing is ≥100 MΩ

Action response test: Power-on/power-off response time

EMC test: Immunity and disturbance tests

Project Advantages

Comprehensive hydraulic and electrical safety testing capabilities

High-precision leakage detection (bubble method/pressure drop method)

Complies with domestic and international valve safety standards

Laboratory Configuration

Hydrostatic test bench

Leakage test system (pressure drop method/bubble method)

Safety comprehensive analyzer

Electromagnetic compatibility test anechoic chamber (outsourcing or cooperation)

FAQ
Q: What is the required response time for the solenoid valve? A: Usually, it is required to be ≤1 second. For emergency shut-off valves, it needs to be ≤0.5 seconds to ensure rapid isolation under abnormal working conditions.
