Compatibility test

Test Background

The seals inside the valve and the valve body material need to be compatible with the coolant for a long time and need to work in coordination with the pump and sensors. Insufficient compatibility may cause corrosion, swelling, or inaccurate control.

Test Introduction

The compatibility test verifies the comprehensive matching of the valve in the liquid cooling system through the static corrosion test of the coolant and the flow linkage control test of the pump-sensor-valve.

Testing Objectives

Verify the compatibility of the valve body and sealing materials with the coolant

Evaluate the response consistency of the valve in dynamic control

Ensure there are no abnormalities when working in coordination with the pump and sensor

Verify the compatibility of communication and control protocols

Test Standards

ASTM D2570 Coolant compatibility test

GB/T 17213 Control valve linkage test

Modbus/I2C communication protocol compatibility specification

Customer-defined linkage control requirements

Applicable Products/Fields

Suitable for the compatibility verification of various valves in the liquid cooling system during CDU integration.

Test Content

Material compatibility test: Immersion corrosion of metal/non-metal materials

Seal swelling test: Changes in volume and hardness

Linkage control test: Form a closed-loop control with the pump and sensor

Flow stability test: Flow fluctuations under PID regulation

Project Advantages

Covers multi‑dimensional compatibility across materials, control systems and overall system

Capable of simulating actual CDU control logic

Provides compatibility evaluation and control parameter optimization recommendations

Laboratory Configuration

Constant-temperature soaking test chamber

Valve performance test platform (with control signal interface)

Programmable Logic Controller (PLC)

Flow/pressure/temperature synchronous monitoring system

FAQ
Q: How do solenoid valves and control valves cooperate in a liquid-cooling system? A: The shut-off valve is used for fault isolation, and the control valve is used for flow control. The two cooperate to achieve system redundancy and precise regulation.
